CYCTRAC EM10 Carbon Electric Mountain Bike

Experience next-level trail riding with the CYCTRAC EM10, a high-performance carbon fiber electric mountain bike designed for power, control, and endurance. Built with a lightweight high modulus carbon frame, advanced suspension system, and the reliable Bafang M560 mid-drive motor, the EM10 is ready for aggressive mountain trails, long-distance adventures, and high-speed off-road riding.

Available in multiple drivetrain configurations including Shimano Deore 12-Speed and Wheeltop Wireless 12-Speed, the EM10 delivers smooth shifting, strong climbing capability, and premium riding comfort.

Key Features

• Lightweight high modulus carbon fiber frame
• Powerful Bafang M560 48V 500W mid-drive motor
• Massive 140Nm torque for steep climbs
• Samsung 720Wh integrated lithium battery
• Up to 120–140KM riding range with pedal assist
• Shimano Deore 12-speed or Wheeltop wireless drivetrain options
• Full suspension MTB design with 145mm rear travel
• Optional ROCKSHOX 35S air suspension fork
• Hydraulic 4-piston disc brakes for maximum stopping power
• MAXXIS 29"/27.5" MTB tires for superior grip
• Bluetooth-enabled LCD display with BafangGo App support
• USB Type-C charging support on display
• IPX6 waterproof rating for all-weather riding

Available Configurations

Drivetrain Options

• Shimano Deore M6100 12-Speed + M560 500W (LOW)
• Shimano Deore M6100 12-Speed + M560 500W (HIGH)
• Wheeltop EDS OX Wireless 12-Speed + M560 500W (HIGH)

Bike Sizes

• 27.5" × 16"
• 29" × 16"
• 27.5" × 18"
• 29" × 18"

Color Options

• Sky Blue
• Dark Gray
• Dark Green
• Red
• Holographic Black

Suspension Options

• Standard Suspension
• ROCKSHOX 35S Air Fork Upgrade

Technical Specifications

Frame & Suspension

• Frame: High modulus carbon fiber
• Rear Suspension: DNM air shock 200×55
• Rear Travel: 145mm
• Internal cable routing
• Boost thru-axle design

Motor & Battery

• Motor: Bafang M560 Mid Drive
• Power Output: 48V 500W
• Max Torque: 140Nm
• Battery: Samsung 21700 Li-ion 720Wh
• Charging Time: 5–6 hours
• Speed Limit: 25KM/H default (up to 45KM/H)

Drivetrain

• Shimano Deore M6100 12-Speed
• Optional Wheeltop EDS OX Wireless 12-Speed
• SUNSHINE 11-50T cassette
• SUMC 12-speed chain

Braking System

• TEKTRO M535 hydraulic disc brakes
• 4-piston calipers
• 203mm front & rear rotors

Wheels & Tires

• MAXXIS 29"/27.5" × 2.4" tires
• Double-wall alloy rims
• Boost hubs with sealed bearings

Smart Features

• Bafang C245 LCD Display
• Bluetooth connectivity
• BafangGo mobile app support
• USB Type-C charging port
• IPX6 waterproof protection
